We know that further epitaxial layers need to be built on top of some wafer substrates for device fabrication, typically LED light-emitting devices, which require GaAs epitaxial layers on top of silicon substrates; SiC epitaxial layers are grown on top of conductive SiC substrates for building devices such as SBDs, MOSFETs, etc. for high voltage, high current and other power applications; GaN epitaxial layers are built on top of semi-insulating SiC substrates for building HEMTs and other RF applications.

According to the research results, TaC coating can act as a protection and isolation layer to extend graphite component life, improve radial temperature uniformity, maintain SiC sublimation stoichiometry, suppress impurity migration, and reduce energy consumption. Ultimately a TaC-coated graphite crucible set is expected to improve SiC PVT process control and product quality.

Silicon carbide (SiC) has important applications in areas such as power electronics, high-frequency RF devices, and sensors for high-temperature-resistant environments due to its excellent physicochemical properties. However, the slicing operation during SiC wafer processing introduces damages on the surface, which, if left untreated, can expand during the subsequent epitaxial growth process and form epitaxial defects, thus affecting the yield of the device.

Currently, many semiconductor devices employ mesa device structures, which are predominantly created through two types of etching: wet etching and dry etching. While the simple and rapid wet etching plays a significant role in semiconductor device fabrication, it has inherent drawbacks such as isotropic etching and poor uniformity, which result in limited control when transferring small-sized patterns. Dry etching, however, with its high anisotropy, good uniformity, and repeatability, has become prominent in semiconductor device fabrication processes. The term “dry etching” broadly refers to any non-wet etching technology used for removing surface materials and transferring micro and nano patterns, including laser etching, plasma etching, and chemical vapor etching. The dry etching discussed in this text specifically pertains to the narrow application of processes using plasma discharge—either physical or chemical—to modify material surfaces.

Homoepitaxy and heteroepitaxy play pivotal roles in material science. Homoepitaxy involves the growth of a crystalline layer on a substrate of the same material, ensuring minimal defects due to perfect lattice matching. In contrast, heteroepitaxy grows a crystalline layer on a different material substrate, which can lead to challenges like lattice mismatch. These processes are crucial in advancing semiconductor devices and thin films. For instance, heteroepitaxy significantly impacts microelectronics and quantum optics, contributing to innovations like Light Emitting Diodes.
