Taiwan's Power Semiconductor Manufacturing Corporation (PSMC) has announced plans to build a 300mm wafer fab in Japan in collaboration with SBI Holdings. The purpose of this collaboration is to strengthen Japan's domestic IC (integrated circuit) supply chain, with a particular focus on circuits for AI edge computing and packaging technologies.

Chemical vapor deposition CVD refers to the introduction of two or more gaseous raw materials into a reaction chamber under vacuum and high temperature conditions, where the gaseous raw materials react with each other to form a new material, which is deposited on the wafer surface.

Gallium oxide (Ga2O3) as an "ultra-wide bandgap semiconductor" material has garnered sustained attention. Ultra-wide bandgap semiconductors fall under the category of "fourth-generation semiconductors," and in comparison to third-generation semiconductors such as silicon carbide (SiC) and gallium nitride (GaN), gallium oxide boasts a bandgap width of 4.9eV, surpassing silicon carbide's 3.2eV and gallium nitride's 3.39eV. A wider bandgap implies that electrons require more energy to transition from the valence band to the conduction band, endowing gallium oxide with characteristics like high voltage resistance, high-temperature tolerance, high power capability, and radiation resistance.

The history of silicon carbide (SiC) dates back to 1891, when Edward Goodrich Acheson accidentally discovered it while attempting to synthesize artificial diamonds. Acheson heated a mixture of clay (aluminosilicate) and powdered coke (carbon) in an electric furnace. Instead of the expected diamonds, he obtained a bright green crystal adhering to the carbon. This crystal had a hardness second only to diamond, and was thus named carborundum. In 1904, French-Jewish chemist Henri Moissan discovered rare natural silicon carbide minerals while studying meteorite samples from the Diablo Canyon in Arizona, USA. He named these minerals moissanite, and his discovery earned him the 1906 Nobel Prize in Chemistry.

Silicon carbide (SiC), a prominent structural ceramic, is renowned for its exceptional properties, including high-temperature strength, hardness, elastic modulus, wear resistance, thermal conductivity, and corrosion resistance. These attributes make it suitable for a wide range of applications, from traditional industrial uses in high-temperature kiln furniture, burner nozzles, heat exchangers, sealing rings, and sliding bearings, to advanced applications like ballistic armor, space mirrors, semiconductor wafer chucks, and nuclear fuel cladding.

Homoepitaxy and heteroepitaxy play pivotal roles in material science. Homoepitaxy involves the growth of a crystalline layer on a substrate of the same material, ensuring minimal defects due to perfect lattice matching. In contrast, heteroepitaxy grows a crystalline layer on a different material substrate, which can lead to challenges like lattice mismatch. These processes are crucial in advancing semiconductor devices and thin films. For instance, heteroepitaxy significantly impacts microelectronics and quantum optics, contributing to innovations like Light Emitting Diodes.
