The third generation of semiconductor materials AlN belongs to the direct bandgap semiconductor, its bandwidth of 6.2 eV, with high thermal conductivity, resistivity, breakdown field strength, as well as excellent chemical and thermal stability, is not only an important blue light, ultraviolet materials, or electronic devices and integrated circuits, important packaging, dielectric isolation and insulation materials, especially for high-temperature high-power devices. In addition, AlN and GaN have a good thermal match and chemical compatibility, AlN used as GaN epitaxial substrate, can significantly reduce the defect density in GaN devices, improve device performance.

The coated parts in semiconductor silicon single crystal hot field are generally coated by CVD method, including pyrolytic carbon coating, Silicon Carbide coating and Tantalum Carbide coating, each with different characteristics.

The process of monocrystalline silicon growth predominantly occurs within a thermal field, where the quality of the thermal environment significantly impacts crystal quality and growth efficiency. The design of the thermal field plays a pivotal role in shaping temperature gradients and gas flow dynamics within the furnace chamber. Furthermore, the materials used in constructing the thermal field directly influence its lifespan and performance.

The Silicon Carbide (SiC) production process encompasses the preparation of substrate and epitaxy from the materials side, followed by chip design and manufacturing, device packaging, and finally, distribution to downstream application markets. Among these stages, substrate material processing is the most challenging aspect of the SiC industry. SiC substrates are both hard and brittle, making cutting, grinding, and polishing extremely difficult. This increases the likelihood of defects during processing and reduces the yield rate. Currently, major international SiC manufacturers are planning to transition from 6-inch to 8-inch SiC wafers. Overcoming the challenges associated with 8-inch substrates has become a critical benchmark for the SiC industry. This article will introduce the key parameters of SiC substrates.

Silicon carbide substrate is a compound semiconductor single crystal material composed of two elements, carbon and silicon. It has the characteristics of large bandgap, high thermal conductivity, high critical breakdown field strength, and high electron saturation drift rate.

The U.S. Department of Energy (DOE) recently confirmed a $544 million loan to SK Siltron, a semiconductor wafer manufacturer under SK Group.
