The development of high-powered blue and UV LEDs has enabled the creation of full-color LED TV displays, as well as white LED automotive and domestic lighting. These LEDs are based on Gallium Nitride, which is deposited on substrate wafers supported by CVD SiC-coated graphite susceptor using the MOCVD process.

Tantalum carbide coating is an important high-strength, corrosion-resistant and chemically stable high-temperature structural material with a melting point of up to 4273 °C, one of the several compounds with the highest temperature resistance. It has excellent high-temperature mechanical properties, resistance to high-speed airflow scouring, ablation resistance, and good chemical and mechanical compatibility with graphite and carbon/carbon composites. Therefore, in the epitaxial process of GaN LEDs and SiC power devices such as MOCVD, TaC coating has excellent acid and alkali resistance to H2, HCl, NH3, which can completely protect the graphite substrate material and purify the growth environment.

SiC's own characteristics determine its single crystal growth is more difficult. Due to the absence of Si:C=1:1 liquid phase at atmospheric pressure, the more mature growth process adopted by the mainstream of the semiconductor industry can not be used to grow the more mature growth method-straight pulling method, the descending crucible method and other methods for growth. After theoretical calculations, only when the pressure is greater than 105 atm and the temperature is higher than 3200 ℃, can we get the stoichiometric ratio of Si:C = 1:1 solution. pvt method is currently one of the more mainstream methods.

The development of 3C-SiC, a significant polytype of silicon carbide, reflects the continuous advancement of semiconductor material science. In the 1980s, Nishino et al. first achieved a 4 μm thick 3C-SiC film on a silicon substrate using chemical vapor deposition (CVD)[1], laying the foundation for 3C-SiC thin-film technology.

When cleaning wafers, ultrasonic cleaning and megasonic cleaning are commonly used to remove particles from the wafer surface.
