China quartz tubes Manufacturers, Suppliers, Factory

In their newly released annual report, TSMC Chairman Deyin Liu and CEO Chieh-Jia Wei revealed the progress related to the 2nm process.

Silicon carbide (SiC) ceramic is a type of advanced ceramic material known for its exceptional properties and wide range of applications. It is composed of silicon (Si) and carbon (C) atoms arranged in a crystal lattice structure, resulting in a hard and strong material with excellent thermal and electrical conductivity.

In the semiconductor industry, epitaxial layers play a crucial role by forming specific single-crystal thin films atop a wafer substrate, collectively known as epitaxial wafers. Particularly, silicon carbide (SiC) epitaxial layers grown on conductive SiC substrates produce homogenous SiC epitaxial wafers, which are instrumental in the fabrication of power devices such as Schottky diodes, MOSFETs, and IGBTs, with 4H-SiC substrates being the most widely utilized.

Currently, many semiconductor devices employ mesa device structures, which are predominantly created through two types of etching: wet etching and dry etching. While the simple and rapid wet etching plays a significant role in semiconductor device fabrication, it has inherent drawbacks such as isotropic etching and poor uniformity, which result in limited control when transferring small-sized patterns. Dry etching, however, with its high anisotropy, good uniformity, and repeatability, has become prominent in semiconductor device fabrication processes. The term “dry etching” broadly refers to any non-wet etching technology used for removing surface materials and transferring micro and nano patterns, including laser etching, plasma etching, and chemical vapor etching. The dry etching discussed in this text specifically pertains to the narrow application of processes using plasma discharge—either physical or chemical—to modify material surfaces.

Single crystal silicon and polycrystalline silicon each have their own unique advantages and applicable scenarios. Single crystal silicon is suitable for high-performance electronic products and microelectronics due to its excellent electrical and mechanical properties. Polycrystalline silicon, on the other hand, dominates the field of solar cells due to its low cost and good photoelectric conversion efficiency.

As technology nodes continue to shrink, the formation of ultra-shallow junctions presents significant challenges. Thermal annealing processes including Rapid thermal annealing (RTA) and flash lamp annealing (FLA) are vital techniques that maintain high impurity activation rates while minimizing diffusion, ensuring optimal device performance.
