The CVD process for SiC wafer epitaxy involves the deposition of SiC films onto a SiC substrate using a gas-phase reaction. The SiC precursor gases, typically methyltrichlorosilane (MTS) and ethylene (C2H4), are introduced into a reaction chamber where the SiC substrate is heated to a high temperature (usually between 1400 and 1600 degrees Celsius) under a controlled atmosphere of hydrogen (H2).

The process of isostatic graphite manufacturing is Selecting raw materials, Blending, Molding, Isostatic pressing, Carbonization, Graphitization.

Tantalum carbide coating is an important high-strength, corrosion-resistant and chemically stable high-temperature structural material with a melting point of up to 4273 °C, one of the several compounds with the highest temperature resistance. It has excellent high-temperature mechanical properties, resistance to high-speed airflow scouring, ablation resistance, and good chemical and mechanical compatibility with graphite and carbon/carbon composites. Therefore, in the epitaxial process of GaN LEDs and SiC power devices such as MOCVD, TaC coating has excellent acid and alkali resistance to H2, HCl, NH3, which can completely protect the graphite substrate material and purify the growth environment.

The first generation of semiconductor materials is mainly represented by silicon (Si) and germanium (Ge), which began to rise in the 1950s. Germanium was dominant in the early days and was mainly used in low-voltage, low-frequency, medium-power transistors and photodetectors, but due to its poor high temperature resistance and radiation resistance, it was gradually replaced by silicon devices in the late 1960s. Silicon is still the main semiconductor material in the field of microelectronics due to its high technological maturity and cost advantages.

Electrostatic chucks (ESCs) have become indispensable in semiconductor manufacturing and flat panel display production, offering a damage-free, highly controllable method for holding and positioning delicate wafers and substrates during critical processing steps. This article delves into the intricacies of ESC technology, exploring its principles of operation, various adhesion mechanisms, and fundamental structural components.

An Electrostatic Chuck (ESC) is a device used to hold semiconductor wafers in place during processes such as etching, deposition, or polishing.
