The application areas of SiC-based and Si-based GaN are not strictly separated. In GaN-On-SiC devices, the cost of SiC substrate is relatively high, and with the growing maturity of SiC long crystal technology, the cost of the device is expected to fall further, and it is used in power devices in the field of power electronics.

In the rapidly evolving field of semiconductor manufacturing, even the smallest improvements can make a big difference when it comes to achieving optimal performance, durability, and efficiency. One advancement that is generating a lot of buzz in the industry is the use of TaC (Tantalum Carbide) coating on graphite surfaces. But what exactly is TaC coating, and why are semiconductor manufacturers taking notice of it?

The Silicon Carbide (SiC) production process encompasses the preparation of substrate and epitaxy from the materials side, followed by chip design and manufacturing, device packaging, and finally, distribution to downstream application markets. Among these stages, substrate material processing is the most challenging aspect of the SiC industry. SiC substrates are both hard and brittle, making cutting, grinding, and polishing extremely difficult. This increases the likelihood of defects during processing and reduces the yield rate. Currently, major international SiC manufacturers are planning to transition from 6-inch to 8-inch SiC wafers. Overcoming the challenges associated with 8-inch substrates has become a critical benchmark for the SiC industry. This article will introduce the key parameters of SiC substrates.

Silicon Carbide generally uses the PVT method, with a temperature of more than 2000 degrees, a long processing cycle, and low output, so the cost of Silicon Carbide substrates is very high.

The process of silicon carbide substrate is complex and difficult to manufacture. SiC substrate occupies the main value of the industry chain, accounting for 47%. It is expected that with the expansion of production capacity and the improvement of yield in the future, it is expected to drop to 30%.

Gallium Nitride (GaN) is an important material in semiconductor technology, known for its exceptional electronic and optical properties. GaN, as a wide-bandgap semiconductor, has a bandgap energy of approximately 3.4 eV, making it ideal for high-power and high-frequency applications.
