The tray (base) that supports SiC wafers, also known as a "susceptor," is a core component of semiconductor manufacturing equipment. And what exactly is this susceptor that carries the wafers?

In November 2023, Semicorex released 850V GaN-on-Si epitaxial products for high-voltage, high-current HEMT power device applications. Compared to other substrates for HMET power devices, GaN-on-Si enables larger wafer sizes and more diversified applications, and it can also be quickly introduced into the mainstream silicon chip process in fabs, which is a unique advantage for improving the yield of power devices.

Graphite Boat, stands at the forefront of technological innovation in its industry, featuring a suite of groundbreaking advancements designed to enhance performance, purity, and lifespan. Below, we delve into the core technologies that define graphite boat's excellence:

The third-generation wide bandgap semiconductor materials, such as Gallium Nitride (GaN) and Silicon Carbide (SiC), are renowned for their exceptional optoelectronic conversion and microwave signal transmission capabilities. These materials meet the demanding requirements of high-frequency, high-temperature, high-power, and radiation-resistant electronic devices. Therefore, they have vast application prospects in new-generation mobile communications, new energy vehicles, smart grids, and LED technologies. The comprehensive development of the third-generation semiconductor industry urgently requires breakthroughs in key core technologies, continual advancement in device design and innovation, and a resolution to import dependencies.

The history of silicon carbide (SiC) dates back to 1891, when Edward Goodrich Acheson accidentally discovered it while attempting to synthesize artificial diamonds. Acheson heated a mixture of clay (aluminosilicate) and powdered coke (carbon) in an electric furnace. Instead of the expected diamonds, he obtained a bright green crystal adhering to the carbon. This crystal had a hardness second only to diamond, and was thus named carborundum. In 1904, French-Jewish chemist Henri Moissan discovered rare natural silicon carbide minerals while studying meteorite samples from the Diablo Canyon in Arizona, USA. He named these minerals moissanite, and his discovery earned him the 1906 Nobel Prize in Chemistry.

Gallium Nitride (GaN) epitaxial wafer growth is a complex process, often utilizing a two-step method. This method involves several critical stages, including high-temperature baking, buffer layer growth, recrystallization, and annealing. By meticulously controlling the temperature throughout these stages, the two-step growth method effectively prevents wafer warping caused by lattice mismatch or stress, making it the predominant fabrication method for GaN epitaxial wafers globally.
