Silicon Carbide Columnar Membranes

The ceramic filter cartridge of Semicorex silicon carbide columnar membranes are made from high-purity silicon carbide fine powder, sintered via the recrystallization process at 2400℃. During sintering process, the silicon carbide undergoes a solid-gas-solid phase transition, resulting in a porosity of up to 45% and highly interconnected filtration channels.

Material Properties of the Semicorx ceramic filter cartridge

1. High flux performance.

2. Superior hydrophilicity ( the water contact angle is only 0.3 degrees) and oleophobicity

3. Superb filtration precision

4. Remarkable anti-fouling ability and easy cleaning.

5. Unmatched chemical stability, capable of operating in extreme environments (pH 1-14).

6. Exceptional mechanical strength for wear and impact resistance.

Typically, Semicorex silicon carbide columnar membranes are composed of multiple hexagonal silicon carbide ceramic filter cartridges. This special structural design allows for a more uniform hydraulic distribution in the flow channels during the water treatment and backwashing process, which significantly improves the water yield of ultrafiltration systems and reduces chemical cleaning costs.

The advantages of Semicorex silicon carbide columnar membranes

1. Competitive investment cost, the low system pre-treatment requirements reduce total capital and operational expenditure.

2. Vertical installation, standardized and modular design for simplified system piping

3. Longer service life compared with alumina ceramic membranes and traditional PVDF membranes

4. Excellent compatibility, compatible with conventional organic membrane ultrafiltration systems.

The Application of Semicorex silicon carbide columnar membranes

1. High-standard treatment of drinking water

2. NF&RO Pretreatment

3. Mine water treatment

4. Wastewater treatment in the photovoltaic and semiconductor industries

5. Reclaimed water reuse
