China mechanical sleeve Manufacturers, Suppliers, Factory

In the semiconductor industry, quartz is widely used, and high-purity quartz products are even more important consumables in wafer production. The production of silicon single crystal crucibles, crystal boats, diffusion furnace core tubes, and other quartz components must use high-purity quartz glass products.

SiC substrate material is the core of SiC chip. The production process of the substrate is: after obtaining the SiC crystal ingot through single crystal growth; then preparing the SiC substrate requires smoothing, rounding, cutting, grinding (thinning); mechanical polishing, chemical mechanical polishing; and cleaning, testing, etc. Process

MOCVD is a new vapor phase epitaxial growth technology developed on the basis of vapor phase epitaxial growth (VPE).

Crystal growth is the core link in the production of Silicon Carbide substrates, and the core equipment is the crystal growth furnace. Similar to traditional crystalline silicon-grade crystal growth furnaces, the furnace structure is not very complex and mainly consists of a furnace body, a heating system, a coil transmission mechanism, a vacuum acquisition and measurement system, a gas path system, a cooling system, a control system, etc., among which Thermal field and process conditions determine the quality, size, conductive properties and other key indicators of Silicon Carbide crystals.

The Silicon Carbide (SiC) production process encompasses the preparation of substrate and epitaxy from the materials side, followed by chip design and manufacturing, device packaging, and finally, distribution to downstream application markets. Among these stages, substrate material processing is the most challenging aspect of the SiC industry. SiC substrates are both hard and brittle, making cutting, grinding, and polishing extremely difficult. This increases the likelihood of defects during processing and reduces the yield rate. Currently, major international SiC manufacturers are planning to transition from 6-inch to 8-inch SiC wafers. Overcoming the challenges associated with 8-inch substrates has become a critical benchmark for the SiC industry. This article will introduce the key parameters of SiC substrates.

High-Purity Silicon Carbide Powder features exceptional wide bandgap characteristics, which make it an ideal material for manufacturing high-frequency, high-power electronic devices.
