Gas Inlet Ring for Semiconductor Equipment

Semicorex is a large-scale manufacturer and supplier of Silicon Carbide Coated Graphite Susceptor in China. We focus on semiconductor industries such as silicon carbide layers and epitaxy semiconductor. Our Gas Inlet Ring for Semiconductor Equipment has a good price advantage and cover many of the European and American markets. We look forward to becoming your long-term partner in China.

Send Inquiry

Product Description

Semicorex Gas Inlet Ring for Semiconductor Equipment is SiC Coated, which is a dense, wear-resistant silicon carbide (SiC) coating. It has high corrosion and heat resistance properties as well as excellent thermal conductivity. We apply SiC in thin layers onto the graphite using the chemical vapor deposition (CVD) process.

Our Gas Inlet Ring for Semiconductor Equipment is designed to achieve the best laminar gas flow pattern, ensuring evenness of thermal profile. This helps to prevent any contamination or impurities diffusion, ensuring high-quality epitaxial growth on the wafer chip.

Parameters of Gas Inlet Ring for Semiconductor Equipment

Main Specifications of CVD-SIC Coating
SiC-CVD Properties
Crystal Structure	FCC β phase
Density	g/cm ³	3.21
Hardness	Vickers hardness	2500
Grain Size	μm	2~10
Chemical Purity	%	99.99995
Heat Capacity	J·kg-1 ·K-1	640
Sublimation Temperature	℃	2700
Felexural Strength	MPa (RT 4-point)	415
Young’ s Modulus	Gpa (4pt bend, 1300℃)	430
Thermal Expansion (C.T.E)	10-6K-1	4.5
Thermal conductivity	(W/mK)	300
