Silicon Carbide (SiC) epitaxy is a key technology in the field of semiconductors, particularly for the development of high-power electronic devices. SiC is a compound semiconductor with a wide bandgap, which makes it ideal for applications that require a high-temperature and high-voltage operation.

SiC substrate material is the core of SiC chip. The production process of the substrate is: after obtaining the SiC crystal ingot through single crystal growth; then preparing the SiC substrate requires smoothing, rounding, cutting, grinding (thinning); mechanical polishing, chemical mechanical polishing; and cleaning, testing, etc. Process

The processing of 4H-SiC substrate mainly includes the following steps:

Within the silicon carbide (SiC) industry chain, substrate suppliers hold significant leverage, primarily due to value distribution. SiC substrates account for 47% of the total value, followed by epitaxial layers at 23%, while device design and manufacturing constitute the remaining 30%. This inverted value chain stems from the high technological barriers inherent to substrate and epitaxial layer production. Three major challenges plague SiC substrate growth: stringent growth conditions, slow growth rates, and demanding crystallographic requirements. These complexities contribute to increased processing difficulty, ultimately resulting in low product yields and high costs. Furthermore, the epitaxial layer’s thickness and doping concentration are critical parameters directly impacting the final device performance.

Silicon carbide (SiC), a prominent structural ceramic, is renowned for its exceptional properties, including high-temperature strength, hardness, elastic modulus, wear resistance, thermal conductivity, and corrosion resistance. These attributes make it suitable for a wide range of applications, from traditional industrial uses in high-temperature kiln furniture, burner nozzles, heat exchangers, sealing rings, and sliding bearings, to advanced applications like ballistic armor, space mirrors, semiconductor wafer chucks, and nuclear fuel cladding.

In semiconductor manufacturing, the precision and stability of the etching process are paramount. One critical factor in achieving high-quality etching is ensuring that wafers are perfectly flat on the tray during the process.
