Silicon Carbide (SiC) epitaxy is a key technology in the field of semiconductors, particularly for the development of high-power electronic devices. SiC is a compound semiconductor with a wide bandgap, which makes it ideal for applications that require a high-temperature and high-voltage operation.

The application areas of SiC-based and Si-based GaN are not strictly separated. In GaN-On-SiC devices, the cost of SiC substrate is relatively high, and with the growing maturity of SiC long crystal technology, the cost of the device is expected to fall further, and it is used in power devices in the field of power electronics.

Silicon carbide ceramics offer numerous advantages in the optical fiber industry, including high-temperature stability, low thermal expansion coefficient, low loss and damage threshold, mechanical strength, corrosion resistance, good thermal conductivity, and low dielectric constant. These properties make SiC ceramics an ideal material for fiber optic sensors, lasers, and high-power optical fiber applications. As demand in the optical fiber field increases, the application prospects for silicon carbide ceramics will become increasingly prominent.

Within the silicon carbide (SiC) industry chain, substrate suppliers hold significant leverage, primarily due to value distribution. SiC substrates account for 47% of the total value, followed by epitaxial layers at 23%, while device design and manufacturing constitute the remaining 30%. This inverted value chain stems from the high technological barriers inherent to substrate and epitaxial layer production. Three major challenges plague SiC substrate growth: stringent growth conditions, slow growth rates, and demanding crystallographic requirements. These complexities contribute to increased processing difficulty, ultimately resulting in low product yields and high costs. Furthermore, the epitaxial layer’s thickness and doping concentration are critical parameters directly impacting the final device performance.

To achieve the high-quality requirements of IC chip circuit processes with line widths smaller than 0.13μm to 28nm for 300mm diameter silicon polishing wafers, it is essential to minimize contamination from impurities, such as metal ions, on the wafer's surface.

Semiconductors are materials whose electrical conductivity at room temperature lies between that of insulators and conductors. By introducing impurities, a process known as doping, these materials can become conductors.
